Santa Clarita TV Mounting: Project example: a 55-inch TV taken down, re-hung in the family room and paired with a soundbar — what it looks like and what it costs

The scenario

The house is a single-story ranch home from the mid-century streets of Newhall: 8-foot ceilings, early drywall over wood studs, and in the family room a wall of original wood paneling nailed over that drywall. A low built-in cabinet runs along the paneled wall, with a duplex outlet behind it. The 55-inch TV currently hangs on a cheap fixed bracket in a bedroom, where it was put up by a previous installer with four lag bolts, two of which missed the stud and went into drywall anchors.

The brief has three parts: take the TV down and patch the bedroom wall so it can be painted, hang the TV in the family room over the cabinet on a bracket that can tilt a little, and mount a soundbar beneath it so the sound is better than the panel's own speakers. The paneled wall adds a wrinkle: the paneling is only a quarter inch thick and nailed to the drywall, so the bracket has to reach the studs through both layers, and the paneling has to be drilled cleanly so it does not splinter. The sofa faces the wall from 9 feet.

What the job involves

1. In the bedroom, the installer lifts the TV off its bracket onto a padded blanket, unbolts the old plate, removes the drywall anchors, fills the holes with setting compound, sands them flush and leaves the patch ready for paint.
2. In the family room, studs are located through the paneling with a stud finder on deep scan and confirmed with a thin pilot hole in a spot the new plate will cover; the paneling's nail lines give a second clue to where the studs are.
3. The screen position is marked over the cabinet's center, with the TV's bottom edge leaving room for the soundbar and the cabinet top, and the center of the screen checked against the sofa's eye line from 9 feet.
4. The tilting mount's plate is leveled, the paneling is pre-drilled with a brad-point bit so it does not splinter, and the plate is lag-bolted through the paneling and drywall into two studs and pull-tested.
5. The soundbar's wall bracket is fitted beneath the plate on the same studs, spaced so the bar sits an inch under the TV's bottom edge and clear of the cabinet lid, and leveled to the TV.
6. The TV is hung and locked, the soundbar is mounted and connected by HDMI eARC, both power cords and the HDMI lead drop behind the cabinet to the outlet, and the picture and sound are tested together before the bedroom patch is given a second coat.

Hardware and materials

• Tilting wall mount for 42–65 inch panels, rated above the TV's weight, with lag bolts for two studs
• Universal soundbar wall bracket adjustable for the bar's depth, with its own lag screws into the same studs
• Brad-point drill bit for clean holes in the paneling; stud finder on deep scan; laser level
• Setting-type patching compound, sanding sponge and a putty knife for the bedroom holes; drywall anchors removed and discarded
• HDMI lead with eARC support, cable sleeve for the drop behind the cabinet

Add-ons often paired with this job

• Hide the wires inside the wall — +$79–$149. On a paneled wall concealment is possible but means removing and re-fitting a panel section; most people keep the cables behind the cabinet instead.
• I need the mount supplied — +$40–$120. The old bedroom bracket is usually not worth reusing; a tilting mount is supplied when none has been bought.
• Full-motion (articulating) mount — +$30–$50. An articulating arm is the upgrade when the family room is watched from the kitchen pass-through as well as the sofa.

Why it is done this way

Moving a TV is really two jobs, and the first one — taking it down properly — is where sloppy work shows. Anchors left in the wall, holes left open and a plate yanked out of drywall are what a later painter has to fix; filling and sanding the holes as part of the dismount means the bedroom is ready for the roller the next day. The second job is a fresh mount that is done right this time: lag bolts into real studs through the paneling, not into anchors.

The soundbar goes on the wall rather than the cabinet top because the cabinet lid lifts and the top is used; a bar on its own bracket keeps the gap under the TV even and the cabinet free. A tilting bracket is chosen because the TV sits a little above eye level over the cabinet and a few degrees of downward tilt removes the window reflection from the picture.

What would change the price

• The paneling turns out to be nailed to furring strips over plaster rather than drywall — pilot holes are essential and the wall type line changes.
• The bedroom wall needs painting as well as patching — painting is not part of a TV job and is left ready for a painter.
• The TV moves to a different house rather than a different room — the dismount and the remount are two visits and are priced as such.
• A larger replacement TV goes up in the family room instead — the base rate follows the new size tier.
• The outlet behind the cabinet is a two-prong ungrounded outlet from the house's original wiring — an electrician replaces it before the equipment is plugged in.
